Page 98 - AFMAN 15-111, 12 MAR 2019

AFMAN15-111 12 MARCH 2019 89

Attachment 3

REMARKS

Table A3.1. Automated, Manual, and Plain Language Remarks/Additive and Maintenance Data.

Observed Enter in Remarks Section Manual Automated Supplement Back-up
Condition
Remark
Number

1 Volcanic Report the following information, if known: (1) Name of X M X X
Eruption volcano, (2) Latitude and longitude or direction and distance
from the installation, (3) Date/time UTC of eruption, (4) Size
description, approximate height and direction of movement

of the ash cloud, (5) And any other pertinent data, e.g., MT
AUGUSTINE VOLCANO 70SM SW ERUPTED 231505
LARGE ASH CLOUD EXTENDING TO APRX 30000 FT
MOV NE.

2 Tornadic Encode tornadoes, funnel clouds, or waterspouts in format, X M X X
Activity Tornadic activity_B/E(hh)mm_ LOC/DIR_(MOV), where
TORNADO, FUNNEL CLOUD, or WATERSPOUT
(See Note 1) identifies the specific tornadic activity, B/E denotes the
beginning and/or ending time, (hh)mm is the time of

occurrence (only the minutes are required if the hour can be
inferred from the report time), LOC/DIR is the location
(distance if known) and/or direction of the phenomena from

the installation, and MOV is the movement, if known.
Tornadic activity will be encoded as the first remark after the
"RMK" entry. For example, "TORNADO B13 6 NE" would
indicate that a tornado, which began at 13 minutes past the
hour, was 6SM northeast of the observing location.
