AFMAN15-111  12 MARCH 2019                                                                  33



                   6.9.8.  Column 5 - Weather and Obscurations to Vision. The encoded present weather and
                   obscurations determined to be on station or in the vicinity and effecting visibility or of enough
                   significance to warrant reporting.
                   6.9.9.  Column 3 - Sky Condition. Encoded as the amount of sky that is covered due to clouds
                   and/or obscurations followed by a 3-digit height in hundreds of feet. Sky coverage is expressed
                   using sky clear (SKC), clear (CLR), few (FEW), scattered (SCT), broken (BKN), overcast
                   (OVC), and vertical visibility (VV) and corresponds to 0, 1-2, 3-4, 5-7, and 8 oktas of sky
                   coverage (e.g. FEW004, SCT085, OVC170, VV000).
                   6.9.10.  Columns 7 and 8 - Temperature and Dew Point. Encoded as whole degrees Celsius
                   using 2 digits. Negative values are prefixed with “M” and missing values are omitted (e.g. 07,
                   11, M02).
                   6.9.11.  Column 12 - Altimeter Setting (ALSTG). Prefixed with “A” and encoded as inches of
                   mercury  (iHg)  using  4  digits  truncated  to  the  hundredths  value;  the  decimal  place  is  not
                   encoded (e.g. A2992, A3013, etc.).
                   6.9.12.  Column 17 - Station Pressure. Encoded as iHg using 5 digits rounded down to the
                   nearest five thousandths value with the decimal place included (e.g. 29.925, 28.830, 27.105).
                   Note: Station pressure is only recorded on 3-hourly and 6-hourly METAR observations.
                   6.9.13.  Column  21  -  Total  Sky  Cover.  Encoded  in  oktas  (1/8ths)  of  sky  covered  by
                   obscurations and clouds and corresponds to the maximum coverage type reported in Column
                   3. Note: Total sky cover is not recorded on SPECI observations.
               6.10.  Observation Remarks.   The remarks section of the observation contains additive data as
               well  as  descriptive  remarks  to  expound  on  the  basic  weather  elements  in  the  body  of  the
               observation. Additive data is recorded in code format at specified times and intervals. Descriptive
               remarks are recorded in specified formats as well as plain language and can be time or situation
               dependent.

               6.11.  Recording Late Observations
                   6.11.1.  If a METAR is taken late but within 15 minutes of the standard time (i.e. up to 14
                   minutes past the hour) and no appreciable changes have occurred since the standard  time,
                   record the observation as a METAR using the standard time with no additional remarks.
                   6.11.2.  If a METAR is taken late and significant changes have occurred or the METAR is
                   missed (i.e. more than 15 minutes late), follow the procedures below for the JET Form 3813
                   and AF Form 3803.
                       6.11.2.1.  When using the 3813, if conditions have changed appreciably or the observation
                       is more than 15 minutes late, record and transmit a SPECI. After transmitting the SPECI,
                       record  a  METAR  observation  using  the  standard  time  of  the  missed  observation  and
                       estimates of the conditions probable at the time of the missed observation. Enter “(FIBI)”
                       (Filed But Impractical to Transmit) in Column 13. Save the observation to the form only;
                       this observation is not transmitted.
